Replica Black Oil Tank For Harley-Davidson Knucklehead 1936-1957

Replica Black Oil Tank For Harley-Davidson Knucklehead 1936-1957

$389.59 USD
$389.59 USD
Sale Sold out
Taxes included. Shipping calculated at checkout.
  • Replica 1936 Knucklehead wrap around oil tank, is the original type with female fittings for banjo bolts
  • Features a non embossed smooth top, lower panels and comes with a drain plug
  • Black tank has a zinc plated cap and is equipped with a screw in dipstick that includes a copper sealing washer
  • Tank does not have battery rod tabs
  • Must order banjo bolts and fittings for oil lines separately
  • Lower right hand feed outlet must be tapped larger to fit a banjo bolt
  • Can be used in later applications by changing the battery rods to earth style battery rods
  • Features 1/8 NPT internal threads for vent and return lines
  • The battery compartment dimensions are 5" wide x 4-1/2" long x 7" tall
  • The left vent hole is 3/8"-24 TPI and the right return hole is 1/2"-20 TPI
  • Clear threads with a tap before final assembly
  • Cap is included
  • Requires the purchase of rubber or steel fittings for oil lines
  • Fits:
    • UL 1938-1947
    • EL 1936-1940
    • FL 1941-1957
